Its a 1.0 Megapixel High-performance CMOS, Analog HD output, up to 720P resolution, True Day/Night, Smart IR, Up to 20m IR distance, IP66 Weatherproof.
Switchable TVI/AHD/CVI/CVBS, Effective Pixels- 1280 (H) x 720 (V), Min. illumination- 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR. Signal System – PAL/NTSC.
It can be used with DVR and Can Be Watched Online, its aHigh Quality Branded Product manufactured by using quality assured material and advanced techniques, which make them up to the standard in this highly challenging field.
1 Megapixel High-Performance CMOS
Analog HD Output, up to 720p Resolution
Day/Night Switch
DNR
Smart IR
Up to 20 m IR Distance
Switchable TVI/AHD/CVI/CVBS
IP66
Camera
Image Sensor | 1 MP CMOS Image Sensor |
---|---|
Signal System | PAL/NTSC |
Effective Pixels | 1296(H) × 732(V) |
Min. Illumination | 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR |
Shutter Time | 1/25 (1/30 )s to 1/50,000 s |
Lens | 2.8 mm, 3.6 mm, 6 mm Optional Field of View: 70.9° (3.6 mm), 92° (2.8 mm), 56.7° (6 mm) |
Lens Mount | M12 |
Day & Night | ICR |
Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° |
Synchronization | Internal Synchronization |
Video Frame Rate | 720p@25fps/720p@30fps |
HD Video Output | 1 Analog HD Output |
S/N Ratio | >62dB |
General
Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), Humidity 90% or Less (Non-Condensing) |
---|---|
Power Supply | 12 V Dc±15% |
Power Consumption | Max. 4 W |
Protection Level | IP66 |
IR Range | Up to 20 m |
Dimensions | ф 70 mm × 154.5 mm ( 2.76" × 6.08") |
Weight | 300 g (0.66 lb.) |
