Door Access Control Reader Wiegand 125KHz ID Card Reader EM 4100 Black 101A with IP68 rating
Features
Have the high ingenious receiving,low current and high stability.
Widely apply in access control, time attendance, electronic toll system, anit-theft and RF Identification various area.
It is useful for safety door systerm, easy to connect and use.
With full pc glue in the back side,IP65 Waterproof
Frequency: 125KHZ ID
Body
| Frequency | 125 KHz |
|---|---|
| Read Cards | EM4100 and compatible cards |
| Supporting Cards Operation | Read the Serial Number of ID Cards |
| Interface | Wiegand 26/34 |
| Read Time | < 120 ms |
| Read Distance | 0 - 15 cm |
| Working Voltage/Current | DC 12V/Max 60mA |
| Power Consumption | < 1w |
| System Protection | Power Protection in Reverse Meet. Data Line Compression Resistance Protection. Max. ±15V |
| Data Transferring Distance | 60 - 100 meters |
| Operating Temperature | 0 - 60 |
| Storage Temperature | -20 - 80 |
| Material | Plastic (RoHS) |
| Dimensions | 102*43*16(mm) |
| Operating Humidity | IP65 |
