Manufacturing Logistics Plant & Machinery Metallic Assets Tracking Trolley/ Pallet Tracking
Physical:
Size (L X W X H) in MM | 61.5 x 20 x 7 ( Hole Dia: 3.0 ) |
---|---|
Size (L X W X H) in Inch | 2.4 x 0.7 x 0.2 ( Hole Dia: .11 ) |
Operating Temperature | -40˚C to +80˚C |
Storage Temperature | -40˚C to +80˚C |
IP Rating | IP 67 |
Weight | 7.50 g |
Material | ABS |
Color | Grey |
Attachment | With Foam Adhesive Screw or Revit |
Electrical:
Protocol Operating Mode | EPC Class 1 Gen 2 |
---|---|
Operating Mode | UHF Passive |
Operating Frequency | ETSI: 865-868MHz FCC: 902-928MHz (Available on request) |
IC Type | Alien Higgs 3 |
Memory | TID : 96 bits EPC : 96 bits User : 512 bits |
Data retention Write endurance | 50 years |
Write endurance | 100,000 cycles |
Read Range* | • Up to 9 Meters from a Fixed Reader |
• Up to 4.5 Meter from a Handheld Reader |
Customization Options:
Encoding | Serialized or Variable |
---|---|
Printing | Barcode, QR Code, Logo Etc.-40°C to +85°C |
Laser Engraving | Barcode, QR Code, Logo Etc. |
Adhesive | Foam Adhesive |
IC | Various Options Available, Depending upon requirement |
Versions | 1. Mount on Metal 2. Free Air |
