mBio FM01
$81.00 $101.00
Face Based Time Attendance & Access Control Terminal
FM01 is low cost Facial recognition terminal with multimode biometrics technology. Multi identification validation methods by RFID card, Fingerprint and Face capture combination. The 2.8 inch TFT high-definition color display with elegant feel. The FM01 has TCP/IP communication,P2P network real-time communication, realize transport data with WIFI. Contactless Face capture attendance, easy to adjust. High recognition ability for face capture image even wears glasses, the identification time is less than 0.8 second. It is possible to integrate all kind of applications like ERP, HRMS, Payroll, Attendance and SAP with the device.
Body
| Display | 2.4" Color LCD Screen |
|---|
Functionality
| Faces Capacity | 1000 |
|---|---|
| Fingerprint Capacity | 5000 |
| ID Card Capacity | 5000 |
| Record Capacity | 300000 |
| Card Type | Proximity card |
| Camera Lens | Two high defination camera |
| LED Infrared Lamp | Two imported ultra bright lamp |
| Identify mode | Face, Finger, Card, Password |
| LED Indicator | NA |
| Voice Prompt | Yes |
| Identification Time | ≤1.5sec |
| Keypad Type | T9 input |
| Wiegand/RS485 Interface | NA |
Technicle Specification
| Fingerprint scanner type | 600 DPI Optical Sensor |
|---|---|
| Communication | TCP/IP, USB |
| Internal Battery | Inbuilt Battery Back-up |
| Push Data technology | Yes |
| FRR | 0.01 |
| FAR | 0.0001 |
| Operation Humidity | 20% ~ 80% |
| Operation Temperature | 10° C ~ 60° C |
| Power | DC 9V 1A |
| Finger placement angle | 360° rotation allowed |
Accessories
| Wiring Connections | Electric Lock |
|---|
